Product Advantage
Voltage | Nominal voltage is 48V (often 51.2V, with a charging range of 54.6V–58.4V). |
Capacity | 36 Ampere-hours (Ah) or 36,000mAh, delivering high energy density for longer range compared to lead-acid alternatives. |
Cycle Life | Offers 1500–2500+ cycles at 100% Depth of Discharge (DOD) before capacity drops to 80%. |
Discharge & Power | Typical discharge rates are 1C to 3C, with continuous discharge currents ranging from 30A to 108A, allowing for 1500W-2000W+ motor operation. |
Safety & BMS | Uses LiFePO4 chemistry (LFP) for high thermal stability. Includes an integrated Smart Battery Management System (BMS) for protection against overcharge, over-discharge, over-current, and short circuits. |
Weight | Approximately 12 kg (26.5 lbs) to 17.5 kg (38.5 lbs). |
Temperature Range | Operates effectively in temperatures from -20 degree celsius to 55 degree celsius. |
Technical Parameters
Chemistry | LiFePO4 (Lithium Iron Phosphate) |
Nominal Voltage | 48V or 51.2V |
Capacity | 36 Ah |
Energy | 1.5kWh – 1.8kWh (1539Wh-1843Wh) |
Configuration | Typically 15S6P or 16S |
Max Charge Voltage | 54.6V - 58.4V |
Discharge Cut-off Voltage | ~40V - 42V |
Max Continuous Discharge Current | Typically 40A to 108A (depends on BMS and cell rating) |
Cycle Life | 2000+ to 3000+ cycles |
Weight | Often around 12 kg (can vary by casing) |
Protection | Built-in Smart BMS with balancing |
Charging Temperature | 0 to45 degree celsius |
Discharging Temperature | -20 to 60 degree celsius |
Product Uses
Electric Vehicles (EVs): E-bikes, electric scooters, and low-speed electric vehicles (LEV) require high current output.
Golf Carts & Mobility: Suitable for powering 48V golf carts and personal mobility vehicles.
Solar Energy Storage: Used for storing energy from small to medium solar PV systems and off-grid power storage.
Industrial/Backup Power: Applications include UPS (Uninterruptible Power Supplies), telecommunication backup, AGV (Automated Guided Vehicle) robots, and medical equipment.
It is widely used in fields such as outdoor areas, environ-mental protection industry, communication industry,power industry, fire protection industry, home energystorage, and backup power supply, providing powersupport for various places that require electricity. Thebattery pack has a long cycle li
Compared with lead-acid batteries and gel batteries, lithium batteries perform better in terms of energy and power. They are easier to achieve fast charging and deep discharge, have a longer service life, and can bring users a better experience when used with lights.
The lithium iron phosphate power batteries produced by Huaxing Company feature stable performance, relatively long cycle life, long driving range and high cost-effectiveness. They can provide customized services according to customer requirements. The BMS (Battery Management System) equipped with th
AGV-Specific Lithium Iron Phosphate Batteries: The Reliable Power Core for Intelligent Material Handling.Designed specifically for AGV equipment, this battery integrates safety, durability, and intelligence to support efficient automated material handling operations:Comprehensive Safety Protection:
Ensuring Safe and Secure Mobility.This lithium iron phosphate battery, specifically designed for electric wheelchairs, makes mobility freer and more worry-free with its safety and reliability.Safety Protection, Worry-Free Use.The intelligent protection system comprehensively prevents overcharging, o
The product is mainly applied in the "lightweight trans-portation" fields such as electric two-wheelers, electric three-wheelers, low-speed electric vehicles, and recre-ational sightseeing vehicles. It features light weight, small size, long service life, and is easy to take out or carry.
With the increasing popularity of two-wheeled electric vehicles, the battery is not only the "heart" of the vehicle but also the core of riding safety and experience. Addressing the ever-evolving market demands, we have launched the 72V24AH lithium iron phosphate battery specifically designed for tw
Lithium Iron Phxosphate Battery (LFP Battery), fully known as Lithium Iron Phosphate Lithium-ion Battery, refers to a type of lithium-ion battery that uses lithium iron phosphate (LiFePO₄) as its cathode material.Currently, batteries are typically named after their cathode material, as the anode is
According to a report by Wood Mackenzie, the market share of lithium iron phosphate is expected to increase to over 30% by 2030. Why has lithium iron phosphate battery been so popular for such a long time? The main reasons are as follows: High Safety PerformanceThe P-O bonds in lithium iron phosphat
With the maturation of lithium battery technology and growing market recognition, lithium iron phosphate (LFP) batteries are seeing increasingly widespread use in energy storage, low-speed electric vehicles, and power tools, thanks to their advantages in high safety, long lifespan, and low cost. How
